Hot water radiant panels are selected for tall space buildings to enhance the comfort of the working environment

time：2024-12-11
hits：1776次
source：正弘奥能

With the continuous development of the industrial field, the form and scale of industrial buildings have also been greatly developed, and the traditional convection heating method has also revealed its disadvantages. First of all, the single building is large in scale, the radiator is difficult to arrange, and it is difficult to meet the design temperature requirements. Secondly, the height of the building is high, and the phenomenon of heating on the radiator is serious. When the heater is used for heating, the wind disturbance in the workshop is serious and the temperature is uneven. Due to the serious wind disturbance in the workshop, dust flying in the workshop and poor sanitary conditions, it has an impact on the production process and directly affects the quality of the product.

Compared with the above convective heating system, the increase of air exchange has less impact on the performance of the hot water radiant panel, because the radiation component is not affected by the air exchange, and the convective system must mainly increase the air temperature to maintain comfortable conditions. Hot water radiant panels enable thermal comfort with appropriate air and average radiant temperatures, and without excessive vertical air temperature differences, temperature asymmetries, or excessive air flow. Hot water radiant panels transfer heat directly to surfaces and objects (such as walls and floors). No noise, no air disturbance, avoid air convection ash phenomenon. Even in the industrial workshop where the smoke is relatively large, the staff will feel warm and comfortable.


	In the process of hot water circulation, the air temperature in the building is lower than the object temperature in the infrared irradiation area (generally 2-3 ° C), which reduces the air stratification and convection effect, and the heating system has a high utilization rate of heat energy and good comfort. Therefore, the hot water radiant panel heating system is superior to traditional convection heating equipment such as radiators and heaters, which can efficiently solve the problems of poor convection heating effect and high energy consumption in tall space. The practical application shows that it is a new energy-saving heating technology for tall space buildings.





	<img src="https://www.leadwaypower.com/Uploads/image/20241211/20241211165950_15938.jpg" alt="" />


By Beijing Leadway Power Co., LTD. Promotion and sales of ECOPAN hot water radiation panel is made of metal tube plate, in the factory is prefabricated into 3 meters, 6 meters (special requirements can be prefabricated 2 meters, 4 meters) standard length. Each radiant panel can be connected with a quick connector. Each radiant panel and collection pipe is prefabricated in the factory and tested for safety. With the same dimensional characteristics (pipe diameter, number and spacing, panel width), ECOPAN hot water radiant panels have higher thermal energy efficiency than other products on the market. In addition, because the hot water radiation panel is ceiling-mounted or freely suspended, it is suitable for tall space occasions such as industrial workshops, warehouses, stadiums, garages, shops, auto showrooms, shipyards, and offices.
