How to design a more ideal heating system for large-space buildings?

time：2025-02-17
hits：387次
source：正弘奥能

Large space buildings, such as factory buildings, maintenance warehouses, warehouses, stadiums, exhibition halls and other buildings have poor thermal insulation and high heat consumption. In the cold or severe regions in the north, the use of traditional convection heating in winter heating, such as radiators, heaters are not ideal heating solutions. So, how to design the heating system of this kind of tall space building?


	IMPRESIND gas radiant heating system promoted and sold by Beijing Leadway Power Co., LTD., independent heaters are generally installed outside the building. At the same time, according to the Code for Fire Protection of Building Design: "The use of gas, liquid and solid as fuel or the combustion of gas and liquid for other purposes of various production" fire risk category belongs to Class D. And the gas infrared radiation equipment system performance is very stable, therefore, the use of gas radiation heating will not increase the risk and design difficulty of the building.





	<img src="https://www.leadwaypower.com/Uploads/image/20250217/20250217131506_65253.jpg" alt="" />


IMPRESIND gas radiation system is the use of natural gas, through a special combustion device - generator combustion and radiation of various wavelengths of infrared radiation for heating. Gas radiation heating is a way for heating tall space buildings, especially suitable for intermittent heating buildings, but also suitable for local heating in tall buildings. Its heat is relatively large, and the thermal efficiency is relatively high, the most important is energy saving and environmental protection, it is also very convenient in installation, and the advantages are obvious.

Safe and reliable, stable performance
Mature technology, stable performance, no flammable components, will not increase the fire risk level and design difficulty of the building. Even in cold areas, the equipment can maintain stable operation.

High thermal efficiency, uniform heating
Radiant heat directly irradiates the heating object, the thermal inertia is small, the heating speed is fast, the heat conversion efficiency is high, the body feeling is comfortable and soft, and the phenomenon of local temperature is not uniform.

Intelligent temperature control, convenient operation and maintenance
The control system can set the temperature to run by itself, and can control the temperature according to the requirements of partition and time sharing; Can be independent control, can also be centralized remote control, no need to set up a special post to work or operation.

High efficiency, low cost
In the case of the same indoor air temperature, the air temperature in the radiation heating environment is designed to be 2 ~ 3℃ lower than that of convective heating, which can achieve the purpose of saving energy and reducing costs.

IMPRESIND gas radiant heating system generator burns completely, so that the heat is fully utilized. At the same time, after the heat exchange of the hot fluid inside the radiation tube, part of the product will be used for gas recirculation through the premixing chamber, and heated twice to achieve energy saving and environmental protection and reduce operating costs. Under the premise of establishing the same comfortable conditions, the design temperature of the building during radiation heating can be reduced by 2°C~3°C compared with that during convection heating, which can also save heating energy consumption. At present, Ipside gas radiation heating system has been applied to Beijing Daxing Airport Southern Airlines aircraft maintenance warehouse, Ordos comprehensive free Trade Zone cargo warehouse, China Post Harbin air mail processing center and other key projects in many provinces and cities.
