Application of Infrared Radiation Heating in large Space Industrial Heating

time：2025-02-28
hits：488次
source：正弘奥能

Infrared radiation heating technology, which simulates the principle of heat transfer by the sun, generates infrared rays through radiation heating equipment and directly applies the heat to the objects and people within the heating space. This technology has a wide range of applications, high thermal energy utilization rate, and good comfort. It solves the problems of poor effect and high energy consumption of traditional convective heating methods in high-rise spaces, and is an ideal heating method for high-rise space buildings. Infrared radiation heating methods (such as gas radiation heating systems and hot water radiation panels) have been promoted and widely used in recent years.

· Advantages of Infrared Radiation Heating Technology

1. Reduce investment and land occupation
The system layout is simple and the installation period is short. It saves investment costs. The equipment installation adopts suspension, which does not occupy the usable area within the building and thus saves valuable building land.

2. Safe and reliable, with stable performance
The technology is mature, the performance is stable, and there are no flammable components. It will not increase the fire hazard level of buildings or the design difficulty. Even in extremely cold regions, the equipment can maintain a stable operating state.

3. High thermal efficiency and uniform heating
Radiant heat directly irradiates the heating objects. With small thermal inertia, it heats up quickly, has high thermal conversion efficiency, and provides a comfortable and mild body sensation. There will be no uneven temperature distribution in any local area.

4. Static heating and clean sanitation
The operation is quiet, without strong convective phenomena, no air disturbance, avoiding the dust-raising phenomenon caused by air convection, improving sanitation conditions, and providing a comfortable working environment for employees.

5. Intelligent temperature control, convenient operation and maintenance
The control system can operate automatically based on preset temperature settings. It can also control temperature in different zones and at different times according to requirements. It can be controlled independently or remotely from a central location, without the need for dedicated personnel to be on duty or operate.

6. High efficiency and energy saving, cost reduction
Under the condition of the same indoor air temperature, the air temperature design in the radiant heating environment can be 2-3℃ lower than that in the convective heating environment, which can achieve the purpose of energy conservation and cost reduction.

 · Recommendations for Infrared Radiation Heating Products

IMPRESIND Gas Radiant Heating System

	IMPRESIND Gas Radiant Heating System is an independent heating system, consisting of a generator, radiant tubes and an intelligent temperature control system. The generator burns natural gas and the generated hot fluid flows in the negative pressure centrifugal fan's drive through the aluminum alloy steel material radiant tubes, generating infrared rays, which directly act on the objects and human bodies within the heating area. The generator of the IMPRESIND Gas Radiant Heating System adopts a double fan and a micro-positive pressure negative pressure system design. The micro-positive pressure fan can ensure the stability of the flame without flame overflow, and the negative pressure fan can well elongate the flame in the radiant tubes to ensure the combustion efficiency. Meanwhile, the system's flue gas recirculation technology greatly improves the equipment's heating efficiency.






	<img src="https://www.leadwaypower.com/Uploads/image/20250228/20250228110632_77242.png" alt="" />



ECOPAN Hot Water Radiant Panel

	The hot water radiant panel is made of metal pipe plates. It uses hot water as the heat-conducting medium and flows through the pipeline of the radiant panel to transfer heat to the radiant panel. It generates infrared rays and directly acts on the objects and human bodies within the heating area. The metal plate covers 70% of its surface, increasing the heat transfer area and ensuring the efficient transfer of heat from the pipe to the panel. The hot water radiant panel has higher thermal energy efficiency than other products on the market. Under the same size characteristics (pipe diameter, quantity and spacing, panel width), it can achieve the same heating requirements by using fewer product quantities.






	<img src="https://www.leadwaypower.com/Uploads/image/20250228/20250228110642_81311.png" alt="" />




	The two radiation heating products, namely "IMPRESIND Gas Radiation Heating System" and "ECOPAN Hot Water Radiation Panels", are the main brands of Beijing Leadway Power&nbsp;Co., Ltd. These products feature stable performance, energy conservation and environmental protection, high level of intelligence, and convenient installation. They efficiently address the heating demands of high-rise space buildings such as industrial plants, aircraft maintenance depots, logistics centers, warehouses, large stadiums, exhibition halls, etc. They have been successfully applied to key projects including the heating project of the Beijing Daxing Airport for China Southern Airlines A380 aircraft maintenance depot, the heating renovation project of the maintenance depot of China Southern Airlines at Urumqi Airport, the heating project of Harbin Beer Museum, and the heating projects of swimming pool and tennis hall in Ulanqab City.
